Updated version of the popular AnyTone AT-D878UV PLUS. Now with Analog APRX RX and 500.000 digital contacts.
Please note that the firmware/CPS of the AT-D878UV can not be used for the AT-D878UV PLUS and AT-D878UVII. Using wrong firmware/CPS can damage your radio!
Features
- Dual-mode (Digital + Analog)
- 1.77 inch color TFT Screen
- 4000 channels
- 10000 Talk Groups with 500000 Digital contacts
- ETSI DMR Tier I and II Compliant
- Auto-senses digital or analog reception
- Ranging function between radios with GPS
- Roaming function
General
- Frequency Range: 144 - 146 en 430 - 440 Mhz (na mod 136-174 / 400-520 MHz RX/TX )
- Channel Capacity: 4000 channels
- Channel Spacing: 25KHz (Wide Band) / 12.5KHz (Narrow Band)
- Phase-locked Step: 5KHz, 6.25KHz
- Operating Voltage: 7.4V DC ±20% (3100mAh)
- Frequency Stability: ±2.5ppm
- Operating Temperature: -20?~ +55?
- Size: 129×61×42mm (with battery pack)
- Weight: 293g (with battery pack)
Transmitting Part
- Power Output: VHF: 7/5/2.5/0.2W, UHF: 6/5/2.5/0.2W
- Modulation limit: ±5.0KHz@25KHz (Wide Band) / ±2.5KHz@12.5KHz (Narrow Band)
- Adjacent Channel Power: ?70dB (Wide Band) / ?60dB (Narrow Band)
- Hum & Noise: ?40dB (Wide Band) / ?36dB (Narrow Band)
- Spurious Emission: ?-36dB (Wide Band) / ?-36dB (Narrow Band)
- 4FSK Digital Modulation: 12.5KHz (data) 7K60FXD / 12.5KHz (data+voice) 7K60FXE
- Audio Distortion: ?5%
- Error rate: ?3%
Receiving Part
- Sensitivity (12dB SINAD): ?0.25?V (Wide Band) 0.3uV/-117.4dBm (BER 5%)
- Digital Sensitivity: 0.7uV/-110dBm (BER 1%) ?0.35?V (Narrow Band)
- Adjacent Channel Selectivity: ?70dB (Wide Band) / ?60dB (Narrow Band)
- Spurious Emission: ?-57dB (Wide Band) / ?-57dB (Narrow Band)
- Spurious Rejection: ?70dB (Wide Band) / ?70dB (Narrow Band)
- Blocking: 84db
- Hum & Noise: ?45dB (Wide Band) / ?40dB (Narrow Band)
- Audio Distortion: ?5%
- Audio Power Output: 1000mW/16?
Package Includes:
- AnyTone AT-D878UVII
- 3100 mAh extended life lithium ion battery
- Desk charger w/ AC adapter
- Dual-band antenna
- Belt clip
- Free USB Programming cable and downloadable software
- English user manual
Levering omvang:
- Anytone AT-D878II portofoon
- 3100 mAh li-ion batterij
- Lader 230Vac
- Handleiding
- Dualband antenne
- Riemclip
- USB programmerkabel
- Bluetooth PTT knop
